Affordable, Scalable, Browser-Based

Access Control System

The Neptune systems is comprehensive embedded OS and browser-managed access control systems.
The proven Neptune systems delivers faster set-up, enhanced features, and scalability with tens of thousands systems installed.
These feature-rich, self-contained access systems are designed for small & mid-sized applications where users need to
secure their facilities, manage access of personnel, create and analyze reports, and monitor the system remotely.
The Neptune Series’ comprehensive wizard is fast and intuitive, saving significant set-up time.

It’s Simple...with Impact

alt4 ITEM 이미지 Clickme to see inside

Smart and Powerful features

  • item1

    UL 294 Listed

  • item1

    Browser
    Managed

  • item1

    Cloud
    Management

  • item1

    Secure

  • item1

    Multiple User
    Privileges

  • item1

    Emergency
    Lockdown

  • item1

    Scalability

  • item1

    Low total cost
    of ownership

SMART & SIMPLE User Interface

alt4 ITEM 이미지
Neptune is a browser based access control platform that does not require a PC with dedicated software.
Out-of-the-box you can manage the system from your mobile device or any PC using your favorite browser.
Our easy to use interface enables easy set-up using the Wizzard and integrated tools for user data import.

Which NEPTUNE is right for you?

alt4 ITEM 이미지
“We have a solution to fit your needs and your budget. Our systems are scalable from one door, stand alone access control, to multi-door, multi-floor, multi-tenant access control. Combined with our video integration and cloud based mobile application, you will be able to securely manage and check on your facility everywhere and at any time of the day or night.”

“Small or large systems will benefit from our low total cost of ownership. No dedicated PC’s or servers are required. No special software to install or maintain. Modular hardware and upgradable software makes it easy to expand and maintain existing systems.”

  • item1

    Advantage

  • item1

    Professional

  • item1

    Corporate

Neptune 4DM

Components

  • Board

  • 2Door Controller/2Door Expansion Module

  • Power Controller(12V)
    and battery backup

  • Integrated Power
    Supply(35W)

Neptune 4DMPL

Components

  • Board

  • 2Door Controller/2Door Expansion Module

  • Power Controller(12/24v)
    and battery backup

  • Integrated Power
    Supply(75W)

2 Door Controllers with option add on ACM

4 Door Controllers ACM is pre mounted

Integrated lock power, battery back up and IEC cord.



Power Module Overview





4 Door Controllers Specifications


  • System
    CPU Cortex A53, Quad-Core, 1.5GHz, 64 Bit
    Memory 1 GB, DDR3 plus
    8 GB eMMc
    OS Linux
    Database SQL
    Data Integrity End to End Encryption, SSL, AES256
    System Backup Each panel retains copy of database for data redundancy, SD Micro, FTP
    Network GB Ethernet
    microSD, USB 1X, 2x

  • Inputs
    Tamper Digital Input 1
    Power Fault Digital Input 1
    Supported Doors 4
    In Readers (Wiegand) 4
    Out Readers (Wiegand) 4
    REX Digital Inputs 4
    Door Position Digital Inputs 4
    Auxiliary Digital Inputs 4

  • Ratings
    Wiegand Reader Power (output) 12VDC @ 0.5 Amps, Fused
    Wiegand Reader Input Rating 0-5V DC with Transient Voltage Suppression
    Digital Input Rating 0-5V DC with Transient Voltage Suppression
    Door Lock Outputs / Form C Dry 4
    Door Lock Output Rating 24VDC @ 2.0 Amps
    Auxiliary Outputs / Form C Dry Contact 4
    Auxiliary Output Rating 24VDC @ 2.0 Amps
    Power Requirements 12VDC, 30 Watts / 60 Watts
